fully auto two poles 4 stations stator winding machine

Name: fully auto two poles 4 stations stator winding machine
Brand: WEDE
Price: 1 USD

Buy cheap fully auto two poles 4 stations stator winding machine product

Brand Name : WEDE

Model Number : WD-2A-XSW

Place of Origin : CHINA

MOQ : 1

Payment Terms : Western Union, T/T, L/C

Supply Ability : 20pcs per month

Delivery Time : 45-65 days

Packaging Details : Ply-wooden case

Default loading : stator loading rack which can be connected with auto line

Default fixture mode : auto assembly

Tapping : can do

Stations No. : 4

Contact Now

Stator winding machine is designed with auto fixture assembly. It can complete the winding fully automatic since the operator place the paper inserted stator core onto the holder.

2 poles stator winding machine has 2 holders and 2 fliers, which enable to do 2 stators winding at the same time, and also 2 non-wound insulation material inserted stator in the queue to take over 2 wound stators, which is convenient for the on-line production.

Tapping position view point of shade poles stator coil winding machine:

fully auto two poles 4 stations stator winding machine

Stator ID	Stator OD	Core length	Wire OD	Stroke range
30-50mm	50-90mm	25-60mm	0.25-0.8mm	135-190mm adjustable
Applicable poles No.	Cycle time	Power	Weight	Size
2 poles	52-55s/8pcs for the stator of 300turns with wire OD0.32mm	3.7KW	about 1500KGS	1600x1550x1830mm(no wire rack) 2100x1550x1830mm(with wire rack
